Diagnostic/Prescreening

Wave Analyzer Medica (WAM800) Wavefront Aberrometer

Fully-automatic screening solution for a complete eye physiology analysis and visual needs assessment

WAM 800 is a very intuitive, rapid and fully-automatic wavefront aberrometer that combines several technologies to enable the eye care professional to provide a comprehensive screening of the eye in less than two minutes.

  • Glaucoma screening and monitoring
  • Keratoconus detection
  • Cataract screening
  • Myopia control
  • Patient vision simulation
  • Eye strain and near-vision assessment
  • Virtual workstation available
  • Efficiency in optical environments

Submit Product Support Ticket

Note: Submitting a support ticket will take you to a separate website.

WAM800 Wavefront Aberrometer

Request PricingAdd to cart

WAM705 Paper Roll for Printout

OPTIMIZED COMPREHENSIVE EYE WELLNESS SCREENING

Glaucoma Screening and Monitoring

  • Improved tonometry using fixation point and IOP value automatically corrected according to the corneal thickness
  • Anterior chamber analysis with a precise measurement of iridocorneal angles

Keratoconus Detection

  • Placido rings topography to help analyze over 100,000 points of cornea and provide the Keratoconus probability index
  • 3D simulation of the cornea curvature combined with pupillometry to help get valuable data for contact lens fittings

Cataract Screening

  • Using infrared retro-illumination, WAM 800 provides a detailed view of the crystal lens opacity helpful in identifying cataracts

COMPLETE VISUAL PERFORMANCE EVALUATION

Patients’ pupillary behavioral patterns and spherical aberrations are responsible for the overall loss of visual quality including poor night vision. Thanks to the wavefront technology, WAM 800 provides acuity simulation to give a better understanding of the patient’s vision. The eye care professional can then use the data to show how much vision can be optimized and promote the benefits of night-vision, anti-fatigue, progressive or personalized lenses.

Patient Vision Simulation

  • Individual autorefractometry and pupillary measurement for mesopic and photopic conditions and near vision
  • Easy-to-use day/night simulation of the patient’s vision using the Point Spread Function

Eye Strain and Near-Vision Assessment

  • Real-time evaluation of the patient’s eye fatigue when focusing on nearby objects
  • Automatic display of the eye fatigue by distances in centimeters

Efficiency in Optical Environments

  • Intuitive user interface with quick access to predefined patient protocols
  • Textual and graphical displays to guide the operator through the screening

CAN BE OPERATED RESPECTING A 6-FT DISTANCE

  • An external TV screen with native VGA port
  • 16-ft long VGA cable
  • Bracket for mounting the screen on a wall or on a floor stand
  • Bluetooth mouse connected to a USB port of the WAM (otherwise wired mouse)

REMOVABLE PROTECTION

  • Removable front rest and easy-to-clean patient contact point

LIMITED INTERACTION

  • Control the instrument head position by using the external screen
  • No need to get close to the patient to adjust the chin rest height

EVALUATE FROM A DISTANCE

  • Present results to the patient using the external screen.
  • Export data directly from the screen to the PMS.

Click on each image to enlarge:

thumbnail of WAM 800 Brochure US 07-2020 email

WAM800 Wavefront Aberrometer Brochure

thumbnail of WAM800 03-2021 email

WAM800 Wavefront Aberrometer eFlyer

WAM700+ Demo

WAM800 Eye Strain Feature
